Change to read:
Packaging and storage
Preserve in tight, light-resistant containers.
![](/usp31/uspnf/pub/images/chars/utrif.gif)
Store as per labeling instructions.
USP31
Change to read:
Chromatographic purity
[noteCarry out the procedure as rapidly as possible, avoiding unnecessary exposure of solutions to light and air.
]
Tris buffer solution, Mobile phase, System suitability solution, and Chromatographic system
Proceed as directed in the Assay.
USP31
Test solution
Prepare as directed for Assay preparation.
Procedure
![](/usp31/uspnf/pub/images/chars/utrif.gif)
Inject a volume (about 50 µL) of
USP31 the
Test solution into the chromatograph, record the chromatograms for at least two times the retention time of the calcitriol peak, identify the impurities listed in
Table 1, and measure the peak responses. Calculate the percentage of any individual impurity in the portion of Calcitriol taken by the formula:
100(ri / rs)
in which
ri is the peak response of any individual peak other than the main calcitriol peak and the pre-calcitriol peak; and
rs is the sum of the responses of all the peaks: in addition to not exceeding the limits in
Table 1, not more than 1.0% of total impurities is found. Disregard any peak less than 0.1%.
Table 1
Name |
Relative Retention Time |
Limit (%) |
Triazoline adduct of pre-calcitriol |
0.43 |
0.1 |
trans-Calcitriol1 |
0.96 |
0.25 |
1 -Calcitriol2 |
1.15 |
0.1 |
Methylene calcitriol3 |
1.5 |
0.25 |
Any other individual unidentified impurity |
|
0.1 |
1
(5 E,7 E)-9,10-secocholesta-5,7,10(19)-triene-1 ![](/usp31/uspnf/pub/images/chars/alpha.gif) ,3 ![](/usp31/uspnf/pub/images/chars/beta.gif) ,25-triol
|
2
(5 Z,7 E)-9,10-secocholesta-5,7,10(19)-triene-1 ![](/usp31/uspnf/pub/images/chars/beta.gif) ,3 ![](/usp31/uspnf/pub/images/chars/beta.gif) ,25-triol
|
3
(5 Z,7 E)-1 ![](/usp31/uspnf/pub/images/chars/alpha.gif) ,3 ![](/usp31/uspnf/pub/images/chars/beta.gif) -dihydroxy-17-(( R)-7-hydroxy-7-methyloctan-2-yl)-9,10-secoandrosta-5,7,10(19)-triene
|
Change to read:
Assay
[noteCarry out the procedure as rapidly as possible, avoiding unnecessary exposure of solutions to light and air.
]
Tris buffer solution
Dissolve 1.0 g of tris(hydroxymethyl)aminomethane in 900 mL of water, adjust with phosphoric acid to a pH of 7.0 to 7.5, dilute with water to make 1000 mL, and mix.
Mobile phase
Prepare a filtered and degassed mixture of acetonitrile and
Tris buffer solution (55:45). Make adjustments if necessary (see
System Suitability under
Chromatography
621![](/usp31/uspnf/pub/images/chars/rang.gif)
).
Standard preparation
![](/usp31/uspnf/pub/images/chars/utrif.gif)
Transfer an accurately weighed quantity of
USP Calcitriol RS to a suitable volumetric flask, dissolve first in acetonitrile (without heating), using 55% of the final volume, then dilute with
Tris buffer solution to volume, and mix to obtain a solution having a known concentration of about 100 µg of calcitriol per mL.
[noteAllow the solution to warm up to room temperature before diluting with
Tris buffer solution to final volume.
]
USP31
System suitability solution
Heat 2.0 mL of the
Standard preparation at 80
![](/usp31/uspnf/pub/images/chars/deg.gif)
for 30 minutes.
Assay preparation
![](/usp31/uspnf/pub/images/chars/utrif.gif)
Transfer an accurately weighed quantity of Calcitriol to a suitable volumetric flask, dissolve first in acetonitrile (without heating), using 55% of the final volume, then dilute with
Tris buffer solution to volume, and mix to obtain a solution having a known concentration of about 100 µg of calcitriol per mL.
[noteAllow the solution to warm up to room temperature before diluting with
Tris buffer solution to final volume.
]
USP31
Chromatographic system (see Chromatography
621
)
The liquid chromatograph is equipped with a 230-nm detector and a 4.6-mm × 25-cm column that contains 5-µm packing L7. The flow rate is about 1 mL per minute. The column temperature is maintained at 40
![](/usp31/uspnf/pub/images/chars/deg.gif)
. Chromatograph the
System suitability solution, and record the peak responses as directed for
Procedure: the relative retention times are about 0.9 for pre-calcitriol and 1.0 for calcitriol; and the resolution,
R, between pre-calcitriol and calcitriol is not less than 3.5. Chromatograph the
Standard preparation, and record the peak responses as directed for
Procedure: the column efficiency is not less than 10,000 theoretical plates; and the relative standard deviation for replicate injections is not more than 1.0%.
Procedure
Separately inject equal volumes (about 50 µL) of the
Standard preparation and the
Assay preparation into the chromatograph, record the chromatograms, and measure the responses for the calcitriol and pre-calcitriol peaks. Calculate the percentage of C
27H
44O
3 in the portion of Calcitriol taken by the formula:
100(CS / CU)(rU / rS)
in which
CS and
CU are the concentrations, in µg per mL, of calcitriol in the
Standard preparation and the
Assay preparation, respectively; and
rU and
rS are the sums of the calcitriol and pre-calcitriol peak responses obtained from the
Assay preparation and the
Standard preparation, respectively.
